Sola Equipment Joe Atkinson inline frames

Precision, Strength and Control.

The Solá Equipment x Joe Atkinson aluminum street skating frames were designed to hold larger, faster rolling wheels in the front or back positions of the frame, while maintaining a low-riding position. Additionally, riders can experiment with different wheel rockering options for a variety of skating experiences.

Note: Requires clearance for 64mm wheels at front and back of soleplates or boots.

TECHNICAL SPECIFICATIONS

• Aluminum Frame Body
• Extruded 6061 T6 hardened aluminum, CNC milled into its final shape
• Treated with a surface-hardening anodized finish
• Universal Frame System (UFS) bolt configuration to fit all corresponding boots
• Max. Wheel Size - 64mm (outside), 60mm (inside). The use of 64mm wheels on the front or back may require soleplate modifications.
• Replaceable H-block System - V2
• The replaceable H-Block is made from a naturally slick and wear resistant injection-molded polymer for all-around street or park skating.
• The V2 h-block design provides increased protection against wheel bite.
• Recommended for flat-rockered setups.
• One-Way Axles - Version 2
• The CNC turned, Black Oxide Steel Alloy screw directly into frame walls, reducing weight and complexity.
• 10mm deep tool cavity helps to keep bolt heads from stripping with regular use
• A nylon patch is bonded to the threads, adding friction to resist loosening from vibration
• Two spare axles included in each package

SIZING

• 255mm wheelbase: Recommended for US 6-9 / EU 38-42
• 275mm wheelbase: Recommended for US 9-12 / EU 42-45
